Taoglas Genesis MA241 2in1 4G/3G/2G 2xMIMO 2M NFC-200, Adhesive Mount Antenna
Taoglas Genesis MA241 2in1 4G/3G/2G 2xMIMO 2M NFC-200, Adhesive Mount Antenna - 698 MHz to 960 MHz, 1710 MHz to 2690 MHz - 5.9 dBi - Cellular Network - Black - Adhesive Mount - Omni-directional - SMA Connector
| $77.22 | Retail $109.95 |
- IP67 Antenna
- 2 * LTE: 2 meter Low Loss NFC-200 SMA(M)ST
- Dimensions: 205.8 x 68 x 12.4mm
- RoHS Compliant
Manufacturer:
Taoglas
Product ID:
68960
Item:
MA241.BI.001
Our Part #
9V7166
Condition
New
$77.22EA
$109.95
$109.95
Availability
Currently out of stock
You may be also interested
Product description
Taoglas Genesis MA241 2in1 4G/3G/2G 2xMIMO 2M NFC-200, Adhesive Mount Antenna - 698 MHz to 960 MHz, 1710 MHz to 2690 MHz - 5.9 dBi - Cellular Network - Black - Adhesive Mount - Omni-directional - SMA Connector
698 MHz to 960 MHz, 1710 MHz to 2690 MHz - 5.9 dBi - Cellular Network - Black - Adhesive Mount - Omni-directional - SMA Connector
Specifications
Antenna Gain
5.9 dBi
Directivity
Omni-directional
Operating Frequency Range
1710 MHz to 2690 MHz
Operating Frequency Range
698 MHz to 960 MHz
Application/Usage
Cellular Network
Connector Type
SMA
Country of origin
Taiwan
Depth
8.10"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Adhesive Mount
Height
0.49"
Limited Warranty
1 Year
Manufacturer
Taoglas
Manufacturer Part Number
MA241.BI.001
Manufacturer Website Address
http://www.taoglas.com
Marketing Information
The MA241 Genesis antenna is an omni-directional fully IP67 waterproof external M2M antenna for use in telematics transportation and remote monitoring applications. It is designed to be mounted directly on glass or plastic in the interior of vehicles.
Typical applications
- HD Video over LTE
- First Responder and Emergency Services
This unique antenna delivers powerful MIMO antenna technology for worldwide 4G LTE bands at 700MHz/800MHz/1700MHz/1800MHz/2600MHz. It enables designers to use only one antenna that covers all common frequencies for LTE and 4G globally.
4G wireless applications demand high speed data uplink and downlink. High efficiency and high gain MIMO antennas are necessary to achieve the required signal to noise ratio and throughput required to solve these challenges. Taoglas also takes care to have high isolation between the two MIMO antennas to prevent self-interference. Low loss cables are used to keep efficiency high over long cable lengths. In contrast smaller MIMO antennas with poorer quality thinner cables will have much reduced efficiency and isolation which would lead to a large drop in system throughput or drops and may indeed not make a system connection at all.
Cable length and connector types are customizable. Contact your regional Taoglas
sales office for support.
Product color
Black
Product Line
Genesis
Product Model
MA241
Product Name
Genesis MA241 2in1 4G/3G/2G 2xMIMO 2M NFC-200 Adhesive Mount Antenna
Product Type
Antenna
Weight (Approximate)
8.80 oz
Width
2.28"
