APC by Schneider Electric Smart-UPS SRT 2200VA RM 120V
APC by Schneider Electric Smart-UPS SRT 2200VA RM 120V - 2U Rack-mountable - 3 Hour Recharge - 120 V AC Input - 120 V AC Output - 6 x NEMA 5-20R, 1 x NEMA L5-20R
| $2,064.52 | Retail $3,215.00 |
- Battery failure notification - Provides early-warning fault analysis on batteries enabling timely preventive maintenance
- ECO Mode - Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
- LCD graphics display - Text and mimic diagrams that display modes of operation, system parameters and alarms.
- Rack/Tower convertible - Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
By:
APC by Schneider Electric
Manufacturer:
Schneider Electric Sa
Product ID:
62372
Item:
SRT2200RMXLA
UPC Code:
760316092082
Our Part #
6C9247
Condition
New
$2,064.52EA
$3,215.00
$3,215.00
Availability
Only 131 Left In Stock
Product description
APC by Schneider Electric Smart-UPS SRT 2200VA RM 120V - 2U Rack-mountable - 3 Hour Recharge - 120 V AC Input - 120 V AC Output - 6 x NEMA 5-20R, 1 x NEMA L5-20R
2U Rack-mountable - 3 Hour Recharge - 120 V AC Input - 120 V AC Output - 6 x NEMA 5-20R, 1 x NEMA L5-20R
Specifications
Battery Energy
1101.6 kJ
DC System Voltage
72 V DC
Load Capacity (VA)
2200 VA
Load Capacity (W)
1800 W
Maximum Operating Elevation
10000 ft
Maximum Storage Elevation
50000 ft
Number of Battery & Surge Outlets
7
Receptacle Detail
6 x NEMA 5-20R
Receptacle Detail
1 x NEMA L5-20R
Sound Emission (A-Weighted)
55 dB(A)
Storage Relative Humidity
0% - 95%
Storage Temperature
-4°F (-20°C) - 122°F (50°C)
UPC Alternates
731304323051 760316092082 818239076495
Waveform Type
Sine Wave
Application/Usage
Server
Application/Usage
Network Workstation
Battery Chemistry
Lead Acid
Battery life
5 Year
Brand Name
APC by Schneider Electric
Country of origin
Philippines
Depth
23"
Environmental Certification
ENERGY STAR 2.0
Environmental Certification
RoHS
Environmental Certification
ENERGY STAR
Environmental Certification
REACH
Environmentally Friendly
Yes
Form factor
Rack-mountable
Height
3.3"
Hot Swappable
Yes
Input frequency
70 Hz
Input voltage
120 V AC
Limited Warranty
3 Year
Load Capacity
2200 VA/1800 W
Manufacturer
Schneider Electric SA
Manufacturer Part Number
SRT2200RMXLA
Manufacturer Website Address
http://www.schneider-electric.com
Marketing Information
Smart-UPS On-Line provides high density true double-conversion on-line power protection for servers voice / data networks medical labs and light industrial applications. Capable of supporting loads from 1 to 20kVA in a rack/tower convertible form the Smart-UPS On-Line is available from 2U to 12U. Recent family extensions at 15 and 20kVA enable support of power hungry blade servers or heavily loaded equipment racks. When business-critical systems require runtime in hours not minutes Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The included PowerChute management software provides unattended graceful shutdown of network operating systems. All models 5kVA and above include an integrated Network Management Card for remote management (optional on models below 5 kVA). The Smart-UPS On-Line family provides customers with a reliable source of uninterruptible power even in demanding power environments including very wide input voltage window extremely tight output voltage regulation frequency regulation internal bypass and input power factor correction.
Marketing Information
Smart-UPS On-Line provides high density true double-conversion on-line power protection for servers voice / data networks medical labs and light industrial applications. Capable of supporting loads from 1 to 20kVA in a rack/tower convertible form the Smart-UPS On-Line is available from 2U to 12U. Recent family extensions at 15 and 20kVA enable support of power hungry blade servers or heavily loaded equipment racks. When business-critical systems require runtime in hours not minutes Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The included PowerChute management software provides unattended graceful shutdown of network operating systems. All models 5kVA and above include an integrated Network Management Card for remote management (optional on models below 5 kVA). The Smart-UPS On-Line family provides customers with a reliable source of uninterruptible power even in demanding power environments including very wide input voltage window extremely tight output voltage regulation frequency regulation internal bypass and input power factor correction.
Maximum Operating Temperature
104°F (40°C)
Network Management
SmartSlot
Number of Batteries
1
Package Contents
Product color
Black
Product Line
Smart-UPS
Product Name
Smart-UPS SRT 2200VA RM 120V
Product Type
Dual Conversion Online UPS
Product Type
Double Conversion Online UPS
Rack Height
2U
Receptacle Type
NEMA 5-20R
Receptacle Type
NEMA L5-20R
Status Indicators
LCD Display
Surge energy rating
340 J
Thermal Dissipation
156.79 W
Typical Battery Recharge Time
3 Hour
Weight (Approximate)
55.01 lb
Width
17"
