Opengear CM7100 Series - Console Server

Emissions:

• FCC Part 15 Subpart B Class A Radiated Emissions 30MHz - 1000MHz
• ICES-003 Issue 4 February 2004 Class A Radiated Emissions 30MHz - 1000MHz
• AS/NZS CISPR 22: 2004 Class A Radiated Emissions 30MHz - 1000MHz
• EN55022: 1998 + A1: 2000 + A2: 2003 Class A Radiated Emissions 30MHz - 1000MHz

Immunity:

• EN55024: 1998 +A1: 2001 +A2: 2003
• IEC61000-4-2: 1995 ESD 8kV Air Discharge (Direct) 4kV Contact Discharge (Direct/Indirect)
• IEC61000-4-3: 1995 Radiated Immunity 3.0V/m 1KHz AM Sine Wave at 80%
• IEC61000-4-4: 1995 EFT/Burst 1.0kV Power Lines 0.5kV I/O Lines
• IEC61000-4-5: 1995 Surge Immunity 1.0kV Common Mode 1.0 kV Differential Mode
• IEC61000-4-6: 1996 Conducted Immunity 3.0 Vrms 80% AM Modulated (1KHz)
• IEC61000-4-11: 1994 Voltage Dips and Interrupts (>95%0.5 periods) (30%25 periods) (>95%250 periods)

Other Agency Approvals:

• CE
• UL 1950
• TUV
• C-Tick
• Security features to support NERC CIP standards
• FIPS 140-2 validated module Certificate #1051

The Opengear CM7100 is a feature-rich console server that simplifies out-of-band management for your network server and power infrastructure in data centers and remote sites. Powerful monitoring diagnostics and remediation features enable efficient recovery from infrastructure fault conditions and maximize uptime. An intuitive dashboard with proactive alerting provides network and IT administrators with real-time status of the core infrastructure.

• 16-96 serial ports out-of-band management of network and server devices
• Simple straight-through cabling to Cisco®-style serial consoles
• Dual Gigabit Ethernet and dual AC power supplies for built-in redundancy
• Embedded internal temperature sensor - CM7196A only
• Audit trail logging to embedded 4GB local storage or remote log server for troubleshooting and compliance
• Link Layer Discovery Protocol (LLDP) discover identify and verify attached devices on your local network.
• Centralize the management of all your enterprise data centers and remote sites with Lighthouse 5
• Integrated RESTful API engine on devices running firmware 4.0 or higher
• AAA including Active Directory and TACACS+ integration lock down access per user and group
• Environmental monitoring with optional EMD5000 module Nagios and SolarWinds integration
• Unified power management of PDU and UPS equipment from 100+ vendors
• Console management raised to a new level with SmartOOB™
• Zero-Touch Provisioning (ZTP) automation over the network without manual user interaction

• CM7100 Series - Console Server
• Rack Mount Kit - Two ears and screws (Part# 590001) Dual A/C Power cords
• 2 x CAT5 Patch Cable 6'
• Cable Kit
• DB9F-RJ45 Straight
• DB9F-RJ45 Crossover
• DB9M-RJ45 Straight
• Loopback test cable
• Quick Start Guide
