StarTech.com Industrial Gigabit PoE Injector - High Speed 90W 802.3bt PoE++ 48V-56VDC Ultra Power Over Ethernet/UPoE Injector -40C to +75C
StarTech.com Industrial Gigabit PoE Injector - High Speed 90W 802.3bt PoE++ 48V-56VDC Ultra Power Over Ethernet/UPoE Injector -40C to +75C - High power industrial gigabit PoE injector 90W 1 Gbps Up to 90W max w/IEEE 802.3bt Type 3/4 PoH (HDBase-T) uPoE/Ultra power over Ethernet, MTBF 500k+hrs IP-30 housing, -40C to 75C - DIN/Wall mountable 48V-56VDC w/redundant pwr inputs - 2yr warranty
| $262.40 | Retail $280.99 |
- WIDE STANDARD COMPATIBILITY: High speed Industrial Gigabit PoE Injector compatible w/ IEEE 802.3bt (PoE++) & previous 90W proprietary POE standards including PoH (HDBase-T), Cisco uPoE, Bosch & AXIS
- 90W POWER BUDGET: Provides up to 90W of auto-negotiated power output for Type 3 and Type 4 PoE/Ultra/UPoE applications like tilt and pan cameras and high power IEEE 802.11ax wireless access points
- TECH SPECS: 1 Gbps
- 48V-56VDC Power Input
- IEEE 802.3af
- IEEE 802.3at
Manufacturer:
StarTech.com
Product ID:
67612
Item:
POEINJ1G90W
UPC Code:
065030889568
Our Part #
8NT073
Condition
New
$262.40EA
$280.99
$280.99
Availability
Only 126 Left In Stock
Product description
StarTech.com Industrial Gigabit PoE Injector - High Speed 90W 802.3bt PoE++ 48V-56VDC Ultra Power Over Ethernet/UPoE Injector -40C to +75C - High power industrial gigabit PoE injector 90W 1 Gbps Up to 90W max w/IEEE 802.3bt Type 3/4 PoH (HDBase-T) uPoE/Ultra power over Ethernet, MTBF 500k+hrs IP-30 housing, -40C to 75C - DIN/Wall mountable 48V-56VDC w/redundant pwr inputs - 2yr warranty
High power industrial gigabit PoE injector 90W 1 Gbps Up to 90W max w/IEEE 802.3bt Type 3/4 PoH (HDBase-T) uPoE/Ultra power over Ethernet, MTBF 500k+hrs IP-30 housing, -40C to 75C - DIN/Wall mountable 48V-56VDC w/redundant pwr inputs - 2yr warranty
Specifications
Input Ports
1 x Gigabit Ethernet
Output Ports
1 x PoE+
Shipping Depth
6.38"
Shipping Height
2.52"
Shipping Width
8.31"
UPC Alternates
065030889568
Certifications & Standards
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3at
- IEEE 802.3af
- IEEE 802.3bt
- IEC 61000-4-2
- IEC 61000-4-4
- IEC 61000-4-5
- EN60950-1
- IP-30
- EN 60068-2-6
- EN 60068-2-27
- EN 60068-2-32
Country of origin
Taiwan
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Form factor
DIN Rail/Wall Mountable
Height
4.1"
Input voltage
56 V DC
Length
3.2"
Limited Warranty
2 Year
Manufacturer
StarTech.com
Manufacturer Part Number
POEINJ1G90W
Manufacturer Website Address
http://www.startech.com
Marketing Information
This Gigabit Power over Ethernet (PoE+) injector supplies power and data connectivity to a Gigabit PoE-compliant device using a standard Ethernet cable.
Flexible Configurations for a Variety of ApplicationsCompatible with IEEE 802.3bt and most previous 90W proprietary PoE (Ethernet) standards including PoH (HDBaseT) Cisco uPoE Bosch and AXIS. One product can cover multiple use requirements to improve standardization and deployment and dual power terminal block inputs provide redundancy for critical applications.
90 Watt Power BudgetAs many typical PoE-enabled switches max out at 30W a high 90W power budget is perfect for demanding Type 3 and Type 4 PoE applications like tilt and pan cameras and high power IEEE 802.11ax wireless access points.
Designed for Harsh EnvironmentsIndustrial features include -40 C to 75 C operating temperature IP-30 rated housing vibration shock and free-fall standard testing.
- Vibration: EN 60068-2-6
- Shock: EN 60068-2-27
- Free-fall: EN 60068-2-32
500000+ hours MTBF rating using Telcordia/Bellcore at 50C for long-term reliability.
The POEINJ1G90W is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Package Contents
- POEINJ1G90W PoE Injector
- Mounting Hardware Kit
- Quick-Start Guide
- Terminal Block
Product color
Black
Product Name
POEINJ1G90W PoE Injector
Product Type
PoE Injector
Protection Type
Surge Protection
Weight (Approximate)
6.14 oz
Width
1.3"
