StarTech.com 2-Port PCI RS232 Serial Adapter Card, Dual Serial DB9 Ports, Expansion/Controller Card, Windows/Linux, Standard/Low Profile
StarTech.com 2-Port PCI RS232 Serial Adapter Card, Dual Serial DB9 Ports, Expansion/Controller Card, Windows/Linux, Standard/Low Profile - Dual port PCI RS232 serial adapter card 16C550 UART/ASIX MCS9865 - Expansion/controller card with speeds up to 115.2Kbps/COM port | 256 byte FIFO | 9th data bit - Even/Odd/No/Space/Mark Parity - Standard bracket (low profile incl) - Windows/Linux
| $27.62 |
- 2 PORT PCI RS232 SERIAL ADAPTER CARD: Controller card w/ 16C550 UART based on ASIX MCS9865, 2x DB9 ports w/bi-directional RS232 speeds up to 115.2Kbps/port, 256 byte FIFO buffer & 9th data bit | Upgraded version of our popular cards PCI2S550_LP & PCI2S550
- TECH SPECS: Speeds up to 115.2Kbps | 16C550 UART | 256 byte FIFO buffer | 5,6,7,8 and 9 bit character | Even, Odd, No, Space or Mark Parity | Auto IRQ & IO assignment | Supports IRQ Sharing | ASIX MCS9865 Chip
- VERSATILE APPLICATIONS: Dual Serial Port PCI Card for PCI desktops/servers used in point of sale terminals, PLCs, CNC Machines, control/automation in factories, scientific sensors, medical equipment, scanners, oscilloscope
- STANDARD PROFILE & LOW PROFILE BRACKET: PCI multiport serial COM card installs using 1x standard bracket (pre-installed) or 2x low profile brackets (incl); Supports Windows 7 and up, Linux 2.6.x to 5.x
- STARTECH.COM ADVANTAGE: IT professionals choice for over 30 years
Manufacturer:
StarTech.com
Product ID:
67831
Item:
PCI2S5502
UPC Code:
065030891318
Our Part #
9KW416
Condition
New
$27.62EA
Availability
Only 9999 Left In Stock
Product description
StarTech.com 2-Port PCI RS232 Serial Adapter Card, Dual Serial DB9 Ports, Expansion/Controller Card, Windows/Linux, Standard/Low Profile - Dual port PCI RS232 serial adapter card 16C550 UART/ASIX MCS9865 - Expansion/controller card with speeds up to 115.2Kbps/COM port | 256 byte FIFO | 9th data bit - Even/Odd/No/Space/Mark Parity - Standard bracket (low profile incl) - Windows/Linux
Dual port PCI RS232 serial adapter card 16C550 UART/ASIX MCS9865 - Expansion/controller card with speeds up to 115.2Kbps/COM port | 256 byte FIFO | 9th data bit - Even/Odd/No/Space/Mark Parity - Standard bracket (low profile incl) - Windows/Linux
Specifications
Number of Serial Ports
2
UPC Alternates
065030891318
Additional Information
Performance
- Serial Protocol RS-232
- Max Baud Rate 115.2 Kbps
- Data Bits 5 6 7 8 9
- FIFO 256 Bytes
- Flow Control None Xon/Xoff RTS/CTS
- Parity None Odd Even Space Mark
- Stop Bits 1 1.5 2
Compatibility
OS Compatibility
- Windows 7 8 8.1 10
- Windows Server 2003 2008 R2 2012 2012 R2 2016 2019
- Linux 2.6.x to 5.x LTS Versions only
Country of origin
China
Environmental Certification
WEEE
Environmentally Friendly
Yes
Form factor
Plug-in Card
Height
4.7"
Host interface
PCI
Limited Warranty
Lifetime
Manufacturer
StarTech.com
Manufacturer Part Number
PCI2S5502
Manufacturer Website Address
http://www.startech.com
Marketing Information
This multiport PCI RS232 serial adapter card lets you add two RS232 (DB9) serial ports to your computer through a PCI slot as if they were native serial ports. The dual port PCI serial card enables you to interact with serial devices such as card readers printers PIN pads and modems at speeds of up to 115.2Kbps.
Maximum Compatibility
With broad OS support including for Windows (7 and up) and Linux (2.6.x to 5.x LTS versions only) this 2 port PCI serial card is easy to integrate into mixed environments. The card comes pre-configured with a full-profile bracket and includes optional low-profile brackets so installation is easy regardless of the case form factor. This card is a direct replacement for PCI2S550_LP and PCI2S550.
Experience Optimal Technology
This PCI to serial adapter supports the following features:
- Industry standard 16C550 UART compatible
- Supports baud rate up-to 115.2Kbps
- 256-byte depth FIFO cache per transmitter and receiver
- Supports 9 8 7 6 5 data bits (one per port)
- Asix MCS9865 chipset
- Low and full-profile brackets included
PCI2S5502 is backed by a StarTech.com lifetime warranty with free 24/5 multi-lingual North American based technical support. StarTech.com has been the IT professionals' choice for over 30 years.
Package Contents
- PCI2S5502 Multiport Serial Adapter
- Full Profile Bracket
- 2 x Low Profile Brackets
- 1 x Quick-Start Guide
Packaged Quantity
1
Product color
Black
Product Name
PCI2S5502 Multiport Serial Adapter
Product Type
Multiport Serial Adapter
Weight (Approximate)
4.97 oz
Width
0.9"
