Mellanox 100GbE QSFP28 CWDM4 Optical Transceiver
Mellanox 100GbE QSFP28 CWDM4 Optical Transceiver - For Data Networking, Optical Network - 1 x LC Duplex 100GBase-CWDM4 Network - Optical Fiber - Single-mode - 100 Gigabit Ethernet - 100GBase-CWDM4
| $785.42 | Retail $1,262.00 |
- Compliant with QSFP28 Standard: SFF-8665 Revision 1.9, SFF-8636 Revision 2.6
- Compliant with CWDM4 MSA Revision 1.1
- High speed I/O electrical interface (CAUI-4)
- Single 3.3V supply voltage
- Maximum power consumption 3.5W
- 0�-70�C case operating temperature
- CWDM EML laser and PIN receiver array
- QSFP28 MSA package with duplex LC connector
- Two Wire Serial Interface with Digital Diagnostic Monitoring
- RoHS compliant
By:
Mellanox
Manufacturer:
Mellanox Technologies Ltd
Product ID:
69203
Item:
MMA1L30-CM
Our Part #
3CD203
Condition
New
$785.42EA
$1,262.00
$1,262.00
Availability
Currently out of stock
Product description
Mellanox 100GbE QSFP28 CWDM4 Optical Transceiver - For Data Networking, Optical Network - 1 x LC Duplex 100GBase-CWDM4 Network - Optical Fiber - Single-mode - 100 Gigabit Ethernet - 100GBase-CWDM4
For Data Networking, Optical Network - 1 x LC Duplex 100GBase-CWDM4 Network - Optical Fiber - Single-mode - 100 Gigabit Ethernet - 100GBase-CWDM4
Specifications
Fiber Mode Supported
Single-mode
Interfaces/Ports Details
1 x LC Duplex 100GBase-CWDM4 Network
Application/Usage
Optical Network
Application/Usage
Data Networking
Brand Name
Mellanox
Compatibility
MSA Compliant
Connector Type
LC
Country of origin
Israel
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
100 Gigabit Ethernet
Limited Warranty
1 Year
Manufacturer
Mellanox Technologies Ltd
Manufacturer Part Number
MMA1L30-CM
Manufacturer Website Address
http://www.mellanox.com
Marketing Information
Mellanox® MMA1L30-CM transceiver is a single mode 4-channel (CWDM4) QSFP28 optical transceiver designed for use in 100 Gigabit Ethernet (GbE) links on up to 2km of single mode fiber. It is also qualified for use in Mellanox InfiniBand EDR end-to-end systems.
The module converts 4 input channels of 25Gb/s electrical data to 4 channels of CWDM optical signals and then multiplexes them into a single fiber using a nominal wavelength of 1310nm for 100Gb/s optical transmission. Reversely on the receiver side the module de-multiplexes a 100Gb/s optical input into 4 channels of CWDM optical signals and then converts them to 4 output channels of electrical data.
It is compliant with the QSFP28 MSA IEEE 802.3bm CAUI-4. Digital diagnostic functions are available via the I²C interface as specified by the QSFP28 MSA.
Rigorous production testing ensures the best out-of-the-box installation experience performance and durability.
Media Type Supported
Optical Fiber
Network Technology
100GBase-CWDM4
Product Line
LinkX
Product Model
MMA1L30
Product Name
100GbE QSFP28 CWDM4 Optical Transceiver
Product Type
QSFP28
Total Number of Ports
1
