NVIDIA MCX515A-CCAT ConnectX-5 EN Adapter Card 100GbE
NVIDIA MCX515A-CCAT ConnectX-5 EN Adapter Card 100GbE - PCI Express 3.0 x16 - 1 Port(s) - Optical Fiber - 100GBase-X - QSFP28 - Plug-in Card
| $900.49 | Retail $1,446.00 |
- Tag matching and rendezvous offloads
- Adaptive routing on reliable transport
- Burst buffer offloads for background checkpointing
- NVMe over Fabric offloads
- Backend switch elimination by host chaining
- Embedded PCIe switch
- Enhanced vSwitch/vRouter offloads
- Flexible pipeline
- RoCE for overlay networks
- PCIe Gen 4.0 support
- RoHS compliant
- ODCC compatible
- Various form factors available
By:
NVIDIA
Manufacturer:
Mellanox Technologies Ltd
Product ID:
69256
Item:
MCX515A-CCAT
UPC Code:
043366115063
Our Part #
4N4651
Condition
New
$900.49EA
$1,446.00
$1,446.00
Availability
Only 200 Left In Stock
You may be also interested
Product description
NVIDIA MCX515A-CCAT ConnectX-5 EN Adapter Card 100GbE - PCI Express 3.0 x16 - 1 Port(s) - Optical Fiber - 100GBase-X - QSFP28 - Plug-in Card
PCI Express 3.0 x16 - 1 Port(s) - Optical Fiber - 100GBase-X - QSFP28 - Plug-in Card
Specifications
UPC Alternates
043366115063 783555149898
Brand Name
NVIDIA
Device Supported
Server
Environmental Certification
RoHS-6
Environmentally Friendly
Yes
Expansion Slot Type
QSFP28
Form factor
Plug-in Card
Height
2.7"
Host interface
PCI Express 3.0 x16
Limited Warranty
1 Year
Manufacturer
Mellanox Technologies Ltd
Manufacturer
NVIDIA Corporation
Manufacturer Part Number
MCX515A-CCAT
Manufacturer Website Address
http://www.nvidia.com
Manufacturer Website Address
http://www.mellanox.com
Marketing Information
NVIDIA MCX515A-CCAT ConnectX-5 EN Adapter Card 100GbE Single-Port QSFP28 PCIe 3.0 x16 Tall Bracket ROHS R6
Up to 100Gb/s Ethernet Adapter Cards
ConnectX-5 Ethernet network interface cards provide high performance and flexible solutions with up to two ports of 100GbE connectivity 750ns latency up to 200 million messages per second (Mpps) and a record setting 197Mpps when running an open source Data Path Development Kit (DPDK) PCIe (Gen 4.0). For storage workloads ConnectX-5 delivers a range of innovative accelerations such as Signature Handover (T10-DIF) in hardware an embedded PCIe Switch and NVMe over Fabric target offloads. ConnectX-5 adapter cards also bring advanced Open vSwitch offloads to telecommunications and cloud data centers to drive extremely high packet rates and throughput with reduced CPU resource consumption thus boosting data center infrastructure efficiency.
ConnectX-5 adapter cards are available for PCIe Gen 3.0 and Gen 4.0 servers and provide support for 1 10 25 40 50 and 100 GbE speeds in stand-up PCIe cards OCP 2.0 and OCP 3.0 form factors. ConnectX-5 cards also offer advanced Multi-Host and Socket Direct technologies.
Media Type Supported
Optical Fiber
Network Technology
100GBase-X
Product Line
ConnectX-5 EN
Product Name
MCX515A-CCAT ConnectX-5 EN Adapter Card 100GbE
Product Type
100Gigabit Ethernet Card
Total Number of Ports
1
Width
5.6"
