TP-LINK MC210CS Gigabit Media Ethernet Converter, 1000Mbps RJ45 to 1000M single-mode SC fiber, up to 15Km/9miles, chassis mountable
TP-LINK MC210CS Gigabit Media Ethernet Converter, 1000Mbps RJ45 to 1000M single-mode SC fiber, up to 15Km/9miles, chassis mountable - 1 x Network (RJ-45) - 1000Base-T, 1000Base-FX - External"
| $30.50 | Retail $32.99 |
- 10/100/1000Mbps Auto-Negotiation RJ45 port supporting Auto-MDI/MDIX
- Complies with IEEE 802.3ab and IEEE 802.3z
- Extends fiber distance up to 9.3 miles (15km)
By:
TP-Link
Manufacturer:
TP-LINK Technologies Co., Ltd
Product ID:
69369
Item:
MC210CS
UPC Code:
807030489535
Our Part #
KA4934
Condition
New
$30.50EA
$32.99
$32.99
Availability
Only 60 Left In Stock
Product description
TP-LINK MC210CS Gigabit Media Ethernet Converter, 1000Mbps RJ45 to 1000M single-mode SC fiber, up to 15Km/9miles, chassis mountable - 1 x Network (RJ-45) - 1000Base-T, 1000Base-FX - External"
1 x Network (RJ-45) - 1000Base-T, 1000Base-FX - External"
Specifications
Fiber Mode Supported
Single-mode
Fiber Optic Wavelength
1310 nm
Maximum Distance Supported
9.32 Mile
UPC Alternates
168141488559 230494832942 801041901628 845973030445
UPC Alternates
168141488559 230494832942 801041901628 801096850742 807030489535 845973030445
Additional Information
- Wavelength: 1310 nm
- Provides switch configuration of Force /Auto transfer mode for FX port
Brand Name
TP-Link
Country of origin
China
Depth
2.9"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
Gigabit Ethernet
Form factor
External
Height
1.1"
Limited Warranty
2 Year
Manufacturer
TP-LINK Technologies Co. Ltd
Manufacturer Part Number
MC210CS
Manufacturer Website Address
http://www.tp-link.com/us
Marketing Information
The MC210CS is a media converter designed to convert 1000BASE-FX fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-FX standards the MC210CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. It works at 1310nm on both transmitting and receiving data.
Media Type Supported
Optical Fiber
Network Technology
1000Base-FX
Network Technology
1000Base-T
Number of Network (RJ-45) Ports
1
Package Contents
- MC210CS Gigabit Ethernet Media Converter
- Power Adapter
- Installation Guide
Power consumption
1.80 W
Power source
Power Adapter
Product Name
MC210CS Gigabit Ethernet Media Converter
Product Type
Transceiver/Media Converter
Total Number of Ports
2
Width
3.7"
