TP-Link CPE510 - 5GHz N300 Long Range Outdoor CPE for PtP and PtMP Transmission
TP-Link CPE510 - 5GHz N300 Long Range Outdoor CPE for PtP and PtMP Transmission - Point to Point Wireless Bridge - 13dBi, 15km+ - Passive PoE Powered w/ Free PoE Injector - Pharos Control (CPE510) White
| $51.76 |
- Built-in 13dBi 2x2 dual-polarized directional MIMO antenna.
- Adjustable transmission power from 0 to 27dBm/500mW.
- System level optimizations for more than 15km long-range wireless transmission (only for paired Point-to-Point or Point-to-MultiPoint transmission).
- TP-Link Pharos maxstream tdma (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for ptmp applications.
- Centralized management system - Pharos control.
- AP/ client/ AP router/ AP client router (WISP) operation modes.
- Passive PoE adapter supports up to 60 meter (200 feet) power over Ethernet deployment and allows the device to be reset remotely.
- Connectivity technology: Wi-Fi Built In.
By:
TP-Link
Manufacturer:
TP-LINK Technologies Co., Ltd
Product ID:
69435
Item:
CPE510
UPC Code:
692753922533
Our Part #
VV3987
Condition
New
$51.76EA
Availability
Only 23 Left In Stock
Product description
TP-Link CPE510 - 5GHz N300 Long Range Outdoor CPE for PtP and PtMP Transmission - Point to Point Wireless Bridge - 13dBi, 15km+ - Passive PoE Powered w/ Free PoE Injector - Pharos Control (CPE510) White
Point to Point Wireless Bridge - 13dBi, 15km+ - Passive PoE Powered w/ Free PoE Injector - Pharos Control (CPE510) White
Specifications
Antenna Gain
13 dBi
Indoor/Outdoor
Outdoor
UPC Alternates
692753922533 696551597870 723856477016 845973070922
Wireless LAN Standard
IEEE 802.11n
Antenna Type
Dual Polarized Antenna
Brand Name
TP-Link
Country of origin
China
Depth
2.2"
Encryption Standard
152-bit WEP
Encryption Standard
WPA2-PSK
Encryption Standard
WPA
Encryption Standard
WPA2
Encryption Standard
TKIP
Encryption Standard
AES
Encryption Standard
64-bit WEP
Encryption Standard
128-bit WEP
Encryption Standard
WPA-PSK
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
Fast Ethernet
Ethernet Technology
Ethernet
Features
Weather Proof
Features
MIMO Technology
Form factor
Pole-mountable
Frequency band
5.85 GHz
Height
1.3"
Input voltage
24 V DC
Manufacturer
TP-LINK Technologies Co. Ltd
Manufacturer Part Number
CPE510
Manufacturer Website Address
http://www.tp-link.com/us
Marketing Information
TP-LINK's 5GHz 300Mbps 13dBi Outdoor CPE the CPE510 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application it is flexible and ideal for point-to-point point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance coupled with user-friendly design makes CPE510 an ideal choice for both business and home users.
Enterprise Hardware
With Qualcomm Atheros enterprise level chipsets high gain antennas and high quality material specially designed enclosure and PoE power supply CPE510 is specially designed for outdoor use and can operate flawlessly in almost any climate with operating temperatures ranging from -30? (-22?) to +70 ? (158?).
Advanced Antenna System
- Built-in High Gain Dual-Polarized Antenna Dedicated metal reflector ensures higher gain and lower noise interference
15km+ Wireless Data Transmission
Specially designed for outdoor uses ideal for long distance wireless data transmission covering a range of 15km+ tested in the field.
15km+ | TP-LINK MAXtream TDMA Technology
As network scale increases wireless competition and collisions among CPEs and base stations will be so enormous that the real throughput of the network will drop resulting in a serious impact on end-user experience. To mitigate these effects the CPE510 uses MAXtream TDMA Technology.
Pharos Control - Centralized Management System
CPE510 also comes equipped with centralized management software that helps users easil manage all the devices in their network from a single PC - Pharos Control. Functions like device discovery status monitoring firmware upgrading and network maintenance can be managed using Pharos Control.
PharOS
User-friendly web-based management system allows professionals to do more specific configurations.
5GHz 300Mbps 13dBi Outdoor CPE CPE510
- Built-in 13dBi Dual-polarized Directional Antenna
- AP / Client / AP Router / AP Client Router (WISP) operation modes
- 6KV Lightning Protection
- Weather Proof Enclosure
- 15KV ESD Protection
- Passive PoE Adapter
Marketing Information
TP-LINK's 5GHz 300Mbps 13dBi Outdoor CPE the CPE510 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application it is flexible and ideal for point-to-point point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance coupled with user-friendly design makes CPE510 an ideal choice for both business and home users.
Enterprise Hardware
With Qualcomm Atheros enterprise level chipsets high gain antennas and high quality material specially designed enclosure and PoE power supply CPE510 is specially designed for outdoor use and can operate flawlessly in almost any climate with operating temperatures ranging from -30? (-22?) to +70 ? (158?).
Advanced Antenna System
- Built-in High Gain Dual-Polarized Antenna Dedicated metal reflector ensures higher gain and lower noise interference
15km+ Wireless Data Transmission
Specially designed for outdoor uses ideal for long distance wireless data transmission covering a range of 15km+ tested in the field.
15km+ | TP-LINK MAXtream TDMA Technology
As network scale increases wireless competition and collisions among CPEs and base stations will be so enormous that the real throughput of the network will drop resulting in a serious impact on end-user experience. To mitigate these effects the CPE510 uses MAXtream TDMA Technology.
Pharos Control - Centralized Management System
CPE510 also comes equipped with centralized management software that helps users easil manage all the devices in their network from a single PC - Pharos Control. Functions like device discovery status monitoring firmware upgrading and network maintenance can be managed using Pharos Control.
PharOS
User-friendly web-based management system allows professionals to do more specific configurations.
5GHz 300Mbps 13dBi Outdoor CPE CPE510
- Built-in 13dBi Dual-polarized Directional Antenna
- AP / Client / AP Router / AP Client Router (WISP) operation modes
- 6KV Lightning Protection
- Weather Proof Enclosure
- 15KV ESD Protection
- Passive PoE Adapter
Number of Network (RJ-45) Ports
1
Outdoor Antenna Range
9.3 Mile
Package Contents
- 5GHz 300Mbps 13dBi Outdoor CPE
- 24V 1A Passive PoE Adapter
- Pole Mounting Straps
- AC Power Cord
- Installation Guide
Power consumption
10.50 W
Product Name
5GHz 300Mbps 13dBi Outdoor CPE
Product Type
Wireless Bridge
System Requirements
Operating Systems:
- Windows 98SE
- Windows NT
- Windows 2000
- Windows XP
- Windows Vista
- Windows 8
- Windows 7
- Mac OS
- NetWare
- UNIX
- Linux
- Google Chrome
- Safari
- Firefox
UNII Minimum Frequency
5.15 GHz
USB
No
Width
4.3"
Wireless Security
- WPA
- WPA2
- WPA-PSK (AES/TKIP)
- WPA2-PSK (AES/TKIP)
- 64/128/152-bit WEP
Wireless Transmission Speed
300 Mbit/s
